Alpena

TREKTEC™ D-Series LED Light Bars + Position Light

TREKTEC™ D-Series LED Light Bars + Position Light

Regular price $141.99 USD
Regular price Sale price $141.99 USD
Sale Sold out
Size
Available To ship To
loading..
Product Instructions

Time for a lighting upgrade. The TrekTec double row line of LED light bars is the perfect addition to your ride. The possibilities are almost endless. Use it on your off-roading vehicles like ATV's, UTV's and side-by-sides, or whatever you use to get work done, like a truck or van. They also work great on sedans or wagons and sport utility vehicles. The D-series come with a white accent light that adds a sleek look and stylish element to any vehicle which you can use on-the-road. Compatible with 12-24V DC systems, IP67 rated for all weather conditions, built with a durable alloy with sealed housing and breather, and stainless steel adjustable angle mounting hardware, this bar is built to last. These bars also come equipped with a low power consumption and optimized circuitry for powersports applications. Add one to your vehicle today and make it yours!

For 14, 17, 22, and 32 models ONLY: These light bars are DOT J581 compliant. This means that they come with a compliant on-road beam and high output off-road beam, offering two levels of brightness in one bar! This innovative combination is new to the market and sure to provide you with the best mix of style and high-level function for all your driving needs.

Feel confident in your purchase - Alpena’s factory is one of the highest rated LED factories in the world and builds quality products you can trust to get the job done. Be sure to check local laws and regulations before using this light bar on public roadways.



Features

  • Alpena designed bright white driving beam LEDs
  • Double LED row for stronger light output
  • Accent light for added style on-the-road
  • Compatible with 12V-24V DC systems
  • Tough alloy construction with sealed housing
  • Stainless steel mounting hardware included
  • Optimized circuitry for powersports applications

Specifications (D14-P):

  • Voltage: 12-24V DC
  • Optics: J581 + off-road
  • Current Draw: 4.2A
  • Power: 50.4W
  • True Lumens: 3,200 lm (off-road beam)
  • Beam Distance @ 1 lux: 278 meters
  • Horizontal Beam Angle: 50
  • 4 wire installation
  • Weight: 1.8 kg
  • 12 LEDs

Specifications (D17-P):

  • Voltage: 12-24V DC
  • Optics: J581 + off-road
  • Current Draw: 4.85A
  • Power: 58.2W
  • True Lumens: 3,400 lm (off-road beam)
  • Beam Distance @ 1 lux: 319 meters
  • Horizontal Beam Angle: 50
  • 4 wire installation
  • Weight: 2 kg
  • 18 LEDs

Specifications (D22-P):

  • Voltage: 12-24V DC
  • Optics: J581 + off-road
  • Current Draw: 8.33A
  • Power: 100W
  • True Lumens: 6,300 lm (off-road beam)
  • Beam Distance @ 1 lux: 375 meters
  • Horizontal Beam Angle: 40
  • 4 wire installation
  • Weight: 2.37 kg
  • 24 LEDs

Specifications (D32-P):

  • Voltage: 12-24V DC
  • Optics: J581 + off-road
  • Current Draw: 12.7A
  • Power: 152.4W
  • True Lumens: 8,700 lm (off-road beam)
  • Beam Distance @ 1 lux: 480 meters
  • Horizontal Beam Angle: 40
  • 4 wire installation
  • Weight: 3.27 kg
  • 36 LEDs

Specifications (D42-P):

  • Voltage: 12-24V DC
  • Optics: Off-road
  • Current Draw: 12.9A
  • Power: 155W
  • True Lumens: 13,000 lm (off-road beam)
  • Beam Distance @ 1 lux: 443 meters
  • Horizontal Beam Angle: 50
  • 3 wire installation
  • Weight: 4.27 kg
  • 48 LEDs

Specifications (D52-P):

  • Voltage: 12-24V DC
  • Optics: Off-road
  • Current Draw: 16.74A
  • Power: 200W
  • True Lumens: 14,500 lm (off-road beam)
  • Beam Distance @ 1 lux: 475 meters
  • Horizontal Beam Angle: 50
  • 3 wire installation
  • Weight: 5.27 kg
  • 60 LEDs
